DS18 10.5" IN-DASH MULTIMEDIA DIN RECEIVER, CAPACITIVE TOUCH SCREEN, BLUETOOTH, MIRROR LINK, USB, ANDROID OPERATING SYSTEM, 64G HARD DRIVE

DS18

Write a Review
SKU:
DS-DDX105ADX

Description

DS18 10.5" IN-DASH MULTIMEDIA DIN RECEIVER, CAPACITIVE TOUCH SCREEN, BLUETOOTH, MIRROR LINK, USB, ANDROID OPERATING SYSTEM, 64G HARD DRIVE

  • 10.5" Single-Din Digital Media Receiver
  • Floating Display ~ Mech-Less ~ Touchscreen
  • Android 10 Operating System
  • BT ~ USB ~ SD ~ AUX ~ AM/FM ~ HDMI
  • DSP ~ Mirror Link ~ GPS ~ SWC
  • IOS and Android Compatible

GENERAL

Rated power source
14.4V DC (10.8V to 15V operation)
Maximum Current Consumption
10 Amp
Dimensions (W x H x D)
Chassis: 178mm x 50mm x 115mm Bezel frame: 170mm x 46mm x 5mm Screen Frame: 266mm x 180mm
Weight
4.5Lb
Processor
Quad Core A53 1.5GHz
Memory RAM
2Gb (DDX10.5AD) / 4Gb (DDX10.5ADX)
Internal Memory (ROM)
32Gb (DDX10.5AD) / 64Gb (DDX10.5ADX)
Operative System
Android Version 10



DISPLAY

Screen Size / Aspect Ratio
10.5 inch / Wide 16:9
Pixels
1280 x 720
Display Type
IPS / Full HD / Capacitive Touch Screen
Temperature Operation
-20?C to +60?C (14?F to 140?F)



AUDIO

Maximum Power Output
54W X 4 Ch / 4 ohm
Continuous Power Output
18W x 4 Ch / 4 ohm @ 14.4V
Pre-output Level
6 Volts @ 14.4V
Equalizer
14 bands totally adjustable from 20Hz to 20KHz on each band Factor Q: Adjustable from 0.4 to 12 Gain: +/- 15dB Presets: Standard / Popular / Rock / Classical / Jazz Custom: 3 User Memories
Crossover
High Pass: Adjustable 20Hz to 20KHz Low Pass: Adjustable 20Hz to 20KHz Slope: Adjustable 6, 12, 24, 36, 48 dB/Oct
Audio Control
Volume / Balance / Fader / Gain / Delay
Frequency Range
FM: 87.5 ~ 107.9 KHz AM: 530 ~ 1710 KHz
Presets Memory
30 Favorite Stations and 12 Presets (6 FM/6 AM)
Regi?n
Selectable (Europe, USA, China, Japan, Eastern Europe, Latin Am?rica, Taiwan, Australia, South Am?rica, Iran, Middle East)
Sensitivity Adjustment
LOC (On/Off) / ST (On/Off)



USB / SD PLAYER / CONNECTIVITY

Type / Class
V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported
AVI, MP4, MP3, WMA, BMP, JPEG.
Resolution Supported
1080P Video
Memory Size Reader
up to 64 Gb
Max Current Supply
1.5 Amp (USB)
Number of USB Ports
3 (1 x Front, 2 x Rear)
Bluetooth Version / Services
V5.0 / Audio Streaming / Hands Free calls
Camera Input
RCA Analog Video up to HD 1080p (Front/Rear)
Video Output
RCA (1 Volt/75 ohm)
A/V Aux Input
Rear RCA Audio and Video / Front 3.5mm Jack Stereo Audio
Microphone
3.5mm Jack external MIC Input
Remote Control
Wired (3.5mm jack) Input
Internet
Wi-Fi wireless connection
HDMI
Yes (output) Selectable Source

Videos

Extra Information
