Description
AUDIOCONTROL A1100.5 5-CHANNEL ALTITUDE AMPLIFIER
Features:
• High/Low Input Modes
• GTO™ Signal Sense
• Linkwitz-Riley Crossovers
• Start-Stop Compliant
• High Power Output in a Sleek Chassis
• ParaBASS® Low Frequency Contouring
• Valet Mode Option
• Optional Remote Level Control (ACR-1)
• EV Compliant up to 17V
Specifications:
Channels: 5/4/3
Inputs: 6
Continuous Power (RMS) at 14.4V:
90W x 4 @ 4Ω +
400W x1 @ 4Ω
125W x 4 @ 2Ω +
600W x 1 @ 2Ω
Maximum Input Voltage:
Low: 6V max
High: 20V max
S/N Ratio (ref: rated power):
95.1 dBA
channels 1-4
103.9 dBA
channel 5
Valet Mode: Y
THD+N:
<0.25% &
<0.75%
Subsonic Filter: Variable
Linkwitz-Riley X-Over:
Mode:
Off
High Pass
Low Pass
Linkwitz-Riley X-Over Freq. Range: 50Hz -5K Hz
Bass Processing: ParaBASS®
Remote Level Control: ACR-1 (optional)
