SPECS

SKU
NXL-X10TPNEO/WH
Nominal Diameter
10"
Nominal Impedance
4 ohm
RMS Power Handing
300W
Maximum Power Handing
900W
Sensitivity (1w/1m)
100dB
Frequency Response
45Hz-22KHz
Recommended Hi Pass Crossover
55Hz

SPECS

Voice Coil Diameter
2"
Voice Coil Former Material

Winding Material

Basket Material
PC Injection Molded Composite
Magnet Weight

THIELE & SMALL PARAMETERS

Vas
33.24L
Xmax
6 mm
Fs
62 Hz
Qms

Qes

Qts
0.7371
Re

MEASUREMENTS

Overall Diameter
10.76" / 273.3 mm
Front Mount Baffle Cutout

Mounting Depth

Overall Depth
15.21" / 386.4 mm
Product Weight
44 lbs
Product Dimensions
28.5 x 18.5 x 16.25
M/C Weight
44 lbs
M/C Dimensions
28.5 x 18.5 x 16.25
M/C QTY
1
Sold In
Pair
