DS18 HYDRO MARINE HEADUNIT WITH TFT VIDEO SCREEN, 2 ZONES, 4V PREOUTS, BLUETOOTH V5.0, RDS, 50W X 4

GENERAL SPECIFICATIONS

SKU
MRX100
Operating Voltage
10.5 – 16 Volts
Current Drain
15 Ampere / (Max)
Low Voltage Warning Alert
YES
Waterproof Rating
IPX6
UV/Salt Protection
YES
Buttons
Rubber + RGB Blacklit (Blue Color)

DISPLAY

Screen Panel
Gorilla Glass with OCA Full Bonding
Backlight
LED

AUDIO

RMS
4 X 18W @ 4 ohm (14.4v)
RMS
4 X 25W @ 4 ohm (14.4v)
MAX
4 X 50W @ 2 ohm (14.4v)
Minimum Load
2 ohm Stable per Channel
Frequency Response
20Hz to 20KHz
RCA Pre-Out Voltage
4 Volts
Output Impedance
500 ohm
Equalizer
2 Bands/ Bass 100Hz / ±10dB / Treble 10Khz / ±10dB
Presets
YES (S-Bass / Vocal / Powerful / Clarity)
Subwoofer Control
Level (-10 to +10)
Audio Zones
2 Zones (Zone 1: Front R+L / Zone 2: R+L)
Independent Zone Control
Yes (Level/Tone)
Audio Input
L+R RCA (Aux Input)

TUNER

FM Frequency Range
87.5 - 107.9 MHz
AM Frequency Range
530 - 1710 KHz
Weather Band
162.40 - 162.55 MHz
NOAA Weather Band
YES
Tuner Presets
18 FM / 12 AM / 6 WB
Radio Data System
YES (AF/TA/NEWS)
IF
10.7MHz (FM), 450KHz (AM)
Sensitivity
4µV (FM), 36dBuV. (AM)
Signal To Noise Ratio
30dB FM
Stereo Separation
25 dB

CONNECTIVITY

BT Version
5.0 + EDR
Audio Streaming
A2DP
USB Compatibility
v2.0
USB Capacity
64 Gb Max
USB Charge Capacity
2.1 Amp
Audio Files Compatibility
MP3, WMA
Remote Control
Wired 3.5mm Jack Input (Compatible with MXRC)

MEASUREMENTS

Product Weight
2 lbs
Product Dimensions
6 x 6 x 7.75
M/C Weight
28 lbs
M/C Dimensions
18.5 x 12.75 x 16.5
M/C QTY
12
Sold In
Piece
