DS18 MARINE AND POWERSPORTS HEADUNIT WITH COLOR SCREEN, 2 ZONES, 4V OUTPUTS, BLUETOOTH, RDS, 40X4 WATTS

GENERAL SPECIFICATIONS

SKU
MRX150
Operating Voltage
10.5 – 16 Volts
Current Drain
15 Ampere / (Max)
Low Voltage Warning Alert
YES (< 10.8V)
Waterproof Rating
IPX6
UV/Salt Protection
YES
Buttons
Rubber + RGB Backlit (Blue Color)

DISPLAY

Screen Panel
Gorilla Glass with OCA Full Bonding
Type
TFT LCD With IPS

AUDIO

RMS
4 x 18W @ 4ohm (14.4v)
RMS
4 x 25W @ 2ohm (14.4v)
MAX
4 x 50W @ 2ohm (14.4v)
Minimum Load
2 ohm Stable per Channel
Frequency Response
20Hz to 20KHz
RCA Pre-Out Voltage
4 Volts
Output Impedance
500 ohm
Equalizer
2 Bands / Bass 100Hz ±10dB / Treble 10Khz ±10dB
Presets
YES (S-Bass / Vocal / Powerful / Clarity)
Subwoofer Control
Level / (-10 to +10)
Audio Zones
2 Zones (Zone 1: Front R+L, Rear R+L / Zone 2: R+L)
Independent Zone Control
YES (Level/Tone)
Audio Input
L+R RCA (Aux Input)

TUNER

FM Frequency Range
87.5 – 107.9 MHz
AM Frequency Range
162.40 – 162.55 MHz
NOAA Weather Band
YES
Tuner Presets
18 FM / 12 AM / 6 WB
Radio Data System
YES (AF/TA/NEWS)
IF
10.7MHz (FM), 450KHz (AM)
Sensitivity
4µV (FM), 36dBuV (AM)
Signal to Noise Ratio
>30dB (FM)
Stereo Separation
>25dB

CONNECTIVITY

BT Version
5.0 + EDR
Audio Streaming
A2DP
USB Compatibility
v2.0
USB Capacity
64 Gb Max
USB Charge Capacity
2.1 Amp
Audio Files Compatibility
MP3, WMA
Remote Control
Wired 3.5mm Jack Input (Compatible with MXRC)

MEASUREMENTS

Product Weight
2.3 lbs
Product Dimensions
6.25 x 6 x 8
M/C Weight
19.5 lbs
M/C Dimensions
13 x 13 x 17
M/C QTY
8
Sold In
Piece
