Marine Headunit LCD screen , 1 Zones, 4 volts Output, BT, RDS 4X40 Watts

SPECS

SKU
MRX1
AM/FM, Antenna
Yes
Audio Imput (L+R)
Yes
USB for music & charging
Yes, Charging 2A
Wired Remote input
Yes

OUTPUTS - REAR CHASSIS

Speaker Power Plug
Yes, Molex Plug 12 pin Water Resistant
Audio output Front (L+R)
Yes
Audio output Rear (L+R)
Yes
Subwoofer output RCA
Yes
Sub out low pass filer
Yes, 80/120/160Hz, Gain 0-12

MEDIA PLAYBACK

USB (64G memory)
Yes
Bluetooth v4.2
Yes
BT streaming ID3 Tag info
Yes

OTHER FEATURES

Operating Voltage
12V
Preamp Output
4V RMS differential
LCD Display Tape
Negative VA
Blacklight
Yes
IR Remote
No
Low Battery Beep
Yes
EEPROM
Yes
Conformal Coating
Yes
IP Rating
IPX 6
UV Resistance
Yes
Salt Spray Resistance
Yes

GENERAL

Power Supply Requeriments
DC 12 Volts, Negative Ground
Chassis Dimensions
115(W) x 115 (D) x 74 (H)
Bass (at 100 Hz)
±10 dB
Treble (at 10 kHz)
±10 dB
Maximum Output Power
4 x 40 watts
RMS continuous power
4 x 15 W @ 4 ohm
Current Drain
10 Ampere (max.)

MEASUREMENTS

Product Weight
2 lbs
Product Dimensions
6 x 6 x 6.75
M/C Weight
26 lbs
M/C Dimensions
18.5 x 12.75 x 14
M/C QTY
12
Sold In
Piece
