Description
NVY AUDIO 6.5" Component Speakers with Water-Resistant Glass Fiber Cone & Neodymium Magnet | 120W RMS 4-Ohm
Premium Motorcycle Audio Upgrade
Designed specifically for motorcycles and motorsports applications, this 6.5” 2-way component set delivers full-frequency detail in open air environments.
Powerful 2-Way Component Performance
The NVY-6GFMTO-N4 is a true 2-way component system featuring a floating-mount neodymium tweeter with an inverted cone and a dedicated passive crossover, ensuring higher dispersion and cleaner sound.
Serious Sound
High-quality crossover components, including Mylar capacitors and silicon-steel coils, maintain signal purity and protect your drivers during high-output playback.
- General Specifications
- Nominal Diameter: 6.5" / 165 mm
- Nominal Impedance: 4 Ohms
- RMS Power Handling: 120 W
- MAX Power Handling: 240 W
- Sensitivity (1W/1m): 90 dB
- Frequency Response: 30 Hz – 20 kHz
- Recommended High-Pass Crossover: 45 Hz
- Number of Ways: 2-Way
- Sold as: Pair
- Grill Included: No
- Woofer Specifications
- Voice Coil Diameter: 1.4" / 35.5 mm
- Voice Coil Former: Aluminum
- Winding Material: Copper
- Cone Material: Glass Fiber
- Surround Material: Rubber
- Basket Material: ABS (Black finish)
- Magnet Type: Neodymium
- Magnet Weight: 2.19 oz
- Cone Shape: Curvilinear
- Speaker Terminals: Spade
- Woofer Measurements
- Overall Diameter: 6.5" / 165 mm
- Overall Depth: 3.5" / 88.5 mm
- Baffle Cutout Diameter:: 5" / 127.3 mm
- Mounting Depth: 2.6" / 67 mm
- Motor Diameter: 1.75" / 44.5 mm
- Thiele & Small Parameters
- Vas (Equivalent Volume): 7.93 L / 0.28 ft³
- Xmax (One-way Excursion): 7.7 mm
- Fs (Free Air Resonance): 70 Hz
- Qms (Mechanical Q): 2.679
- Qes (Electrical Q): 0.957
- Qts (Total Q): 0.705
- Mms (Moving Mass): 16.17 g
- Cms (Compliance): 317 µm/N
- BL Factor: 5.182
- Le (Voice Coil Inductance): 0.3 mH
- Sd (Cone Area): 132.73 cm²
- Re (DC Resistance): 3.6 Ohms
- Mmd (Mechanical Mass w/o air): 15.29 g
- Tweeter Specifications
- Mounting Design: Floating Metal Bracket
- Voice Coil Diameter: 0.8" / 20.4 mm
- Voice Coil Former: Kapton
- Winding Material: CCAW
- Diaphragm Material: Aluminum
- Magnet Type: Neodymium
- Magnet Weight: 1.4 oz
- Crossover Specifications
- Type: 2-Way Passive
- Crossover Point: 3.7 kHz
- Power Handling: 200 W
- Slope: 12 dB/Octave
- Capacitor Type: Mylar
- Coil Type: Silicon Steel Sheet / I-Shaped
- Housing Material: ABS
- Housing Dimensions: 2.95" × 2.1" × 1" (75 × 55 × 26 mm)
