NVY AUDIO Harley-Davidson Street Glide OEM Front Grille Upgrade with Bullet Tweeters & Crossovers (2014-2023)
Pre-Loaded With NVY
Each grille is preloaded with high output NVY bullet tweeters and inline crossovers for crisp, controlled high frequencies at highway speeds.
Designed for Real Riding Conditions
Steel mesh construction with waterproof backing and UV resistant black matte finish ensures durability in heat, rain, and vibration.
- Tweeter Specifications
- Nominal Diameter: 2.5 in (65 mm)
- Nominal Impedance: 4 Ohms
- AES Power Handling: 50 W
- Program Power Handling: 100 W
- Peak Power Handling: 200 W
- Sensitivity (1W/1m): 105 dB
- Frequency Response: 2 kHz – 20 kHz
- Recommended High-Pass Crossover: 4 kHz
- Configuration: Pair
- Body and Features
- Filter (Bass Blocker): 2.2 µF / 50 V
- Bullet Material: ABS
- Terminal Type: Wires
- Body Material: ABS
- Body Color: Black
- Faceplate Color: Black
- Motor
- Voice Coil Diameter: 1 in (25.4 mm)
- Voice Coil Former Material: Kapton
- Winding Material: CCAW
- Diaphragm Material: PEN
- Magnet Material: Neodymium
- Magnet Weight: 0.61 oz
- Tweeter Measurements
- Overall Diameter: 2.5 in (65 mm)
- Overall Depth: 1.4 in (35.5 mm)
- Front Mount Baffle Cutout: 2.2 in (55 mm)
- Mounting Depth: 1.1 in (28.5 mm)
- Grille Measurements
- Overall Diameter: 6.5 in (165.1 mm)
- Overall Depth: 1.4 in (35.5 mm)
- Crossover Measurements
- Overall Length: 2.75 in (70 mm)
- Overall Width: 1.5 in (38 mm)
- Overall Height: 0.9 in (23 mm)
