SPECS

SKU
NXL-X10TPNEO
Nominal Diameter
10"
Nominal Impedance
4 Ohm
RMS Power Handling
300W
MAX Power Handling
900W
Sensitivity (1w/1m)
100 dB
Frequency Response
45Hz - 22KHz
Recommended HI Pass Crossover
55 Hz
Colors Available
Black, White, Red, Carbon Fiber

Body / Features

Enclosure Material
Injection ASA
Marine Grade Type
IP65+UV Stable
RGB LED
Integrated LED-RGB Speaker Lighting, Integrated LED-RGB Acrylic Ring Lighting, and with 6 Core Wires for Lighting and Speaker
Grill Type
ASA + 316 Stainless Metal Mesh
Pair
Yes
Clamps
Die-Cast Adjustable (1"~2") 360 Degree Rotation Mounting Buried Wire or Open Wire Mounting Optional, Included NBR Pad And Stainless Hardware(Screws, Stop Washers, Hexagon wrench, Safety Rope, Screw fastening Glue)
Front Logo
Yes, can be rotated for correct angle display
Rear Logo
Radiator Fixed Position

Woofer Specifications

Voice Coil Diameter
2"
Cone Material
Waterproof Compress Paper
Surround Material
Soft PC Damping Glued
Basket Material
PC Injection Molded Composite
Magnet Material
Neodymium
Magnet Grade
N40H
Passive Radiator
6.1" with LED RGB Light

Tweeter Specifications

Voice Coil Diameter
1.5"
Type
compression driver with CNC solid aluminum horn
Diaphragm Material
polyimide
Magnet Material
Neodymium
Crossover
12dB with over power protection

Thiele & Small Parameters

Equivalent Volume Vas
33.24 L
Excursion (one way) Xmax
6 mm
Free Air Resonance Fs
62 Hz
Total Factor Qts
0.7371

Speaker Measurement

Overall Diameter
10.76" / 273.3 mm
Overall Depth
15.21" / 386.4 mm
Overall Height
14.32" / 363.9 mm
