Description
DS18 HYDRO NANO 2CH FULL RANGE AMPLIFIER - 300W
Key Features
- Marine Full Range
- 2 Channel
- 2 X 100 Watts @ 4 Ohm
- Class D
- Micro
- Water Resistant IP67
GENERAL SPECS
SKU
NXL-N2
Total Watts (Peak)
900W
RMS Power @ 4 ohm
2 x 100W
RMS Power @ 2 ohm
2 x 150W
RMS Power @ 4 ohm Bridge
1 x 300W
AUDIO
Frequency Response
20Hz-20KHz
Signal to Noise Ratio 1W @ 4ā¦
90dB
Total Harmonic Distortion (THD)
0.1%
Low Level Input Range
200mV-5V
Selectable X-Over
HPF/LPF/FULL
X-Over Filter Range
40-500Hz
Bass Boost Range
No
Infrasonic Filter
No
FEATURES 1
Amplifier Class
Digital
Amplifier Type
Stereo Full Range
Number of Channels
2
Minimum Impedance
2ohm (Stereo) / 4ohm (Bridge)
LED Indicator
Power / Protection
Power Input Size
Wired 10Ga OFC
Fuse Size
25A
Thermal Protection
Yes
FEATURES 2
Over-Load Protection
Yes
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (>15V)
Body Color
Aluminum Black and Red
Waterproof Rating
IPX67
Latest Full Range Digital Design Based on IR Platform
Yes
Ultra Compact Design for Easy Installation
Yes
PCB Design with Stable and Reliable 4-Layer Layout
Yes
Quality Control Verification Using AP Instruments
Yes
MEASUREMENT
Overall Length
7.87" / 200mm
Overall Wide
3.67" / 93.4mm
Overall Height
1.56" / 39.8mm
Heatsink Length
7.16" / 182mm
Gross Single Unit Weight
2Lb / 947 kg
Product Weight
2.5 lbs
Product Dimensions
10.25 x 5 x 3
M/C Weight
25.5 lbs
M/C Dimensions
16 x 11 x 10.75
M/C QTY
10
Sold In
Piece
Product Overview
DS18 NXL-N2
Nano Full-Range 2-Channel Marine Amplifier
DS18’s NXL-N2 is a true all-terrain, all-weather 2-channel amplifier built for motorcycles, boats, UTVs, ATVs, and beyond.
Full-Range Power
With up to 900W at its disposal, this compact beast delivers 2x150W @ 2Ω or 2x100W @ 4Ω RMS. Got a custom setup? Run it bridged at 4Ω for a clean 1x300W and drive your favorite full-range driver or midbass combo.
Ready for Anything
The NXL-N2 is 100% sealed and tested for water, dust, and mud resistance. With an IPX67 rating, it’ll shrug off waves, rain, and trail abuse. Designed for real-world powersports and marine installs—not just showroom floor builds.
Dial In Your System
Built-in selectable crossovers (HPF / LPF / FULL) let you tailor the amp’s output to whatever speakers you're running. From crisp mids to hard-hitting low end, you're always in control.
Rock-Solid Design
Inside, a 4-layer PCB keeps signal stable under pressure. It’s designed with full thermal, overload, short-circuit, and over-voltage protection. The fully aluminum chassis doubles as a heatsink to keep things cool.
Small Footprint
At just 7.87" x 3.67" x 1.56", the NXL-N2 fits into tight spaces like bike saddlebags, glove boxes, or side-by-side dashes—perfect for stealthy, performance-first installs.
Get pro-level sound in a compact build with DS18’s NXL-N2.
