SPECS

SKU
NXL-PS8
Nominal Diameter
8" / 203mm
Nominal Impedance
4 ohm
RMS Power Handling
125W
MAX Power Handling
375W
Sensitivity (1w/1m)
93dB
Frequency Response
55Hz - 23Khz
Recommended HI Pass Crossover
70Hz

Body / Features

Enclosure Material
Injection PC+ABS
Marine Grade Type
IP65 + UV Stable
RGB LED
Integrated LED-RGB Speaker Cone + Back Logo Lighting 6 Core Wires for Lighting and Speaker
Grill Type
Injection Molded ASA + UV Coating
Pair
Yes
Clamps
CNC Aluminum base for flat mounting and Die-Cast Solid Aluminum 360° rotation mobile clamps for 1.75" or 2" mast Included
Front Logo
Yes, can be rotated for correct angle display
Rear Logo
Yes, can be rotated for correct angle display
Finish
Matt Black

Woofer Specifications

Voice Coil Diameter
1.2"
Cone Material
Injection Molded UV-Compliant Polypropylene
Surround Material
Butyl
Basket Material
High Temp Injection Molded Composite + UV Coating
Magnet Material
Ferrite + Neodymium
Magnet Grade
Y35 / N40H
Passive Radiator
NO

Tweeter Specifications

Voice Coil Diameter
1"
Type
Dome
Diaphragm Material
Titanium + PEI Surround
Magnet Material
Neodymium
Crossover
6dB/Oct

Thiele & Small Parameters

Equivilant Volume Vas
22.5L / 0.795ft3
Excursion (one way) Xmax
4 mm
Free Air Resonance Fs
50Hz
Total Factor Qts
0.532

Speaker Measurement

Overall Diameter
8.59" / 218.1mm
Overall Depth
6.8" / 173mm
Overall Height (with Mast Clamp)
11.54" / 293.1mm
Overall Height (with Flat Clamp)
9.4" / 238.7mm
