ORION COBALT Series 1500 Watts MAX 2-Channel Class A/B Amplifier

ORION

Write a Review
SKU:
OR-CBA1500.2

Description

ORION COBALT Series 1500 Watts MAX 2-Channel Class A/B Amplifier

Class A/B Amplification – Get the best of both worlds with this amplifier’s Class A/B design, delivering top-tier sound quality with high efficiency so every note is clear and powerful.
Massive 1500-Watt Peak Power – Experience audio with punch and depth, thanks to a peak output of 1500 watts that brings your music to life, filling your space with dynamic, immersive sound.
Precision Audio Control – Take control of your sound with an adjustable crossover that lets you fine-tune audio frequencies, maximizing speaker performance and creating the perfect sound balance.
Customizable Bass Boost – Dial in the bass exactly how you like it with an adjustable bass boost feature, enhancing the low-end response for a powerful, tailored listening experience.
Advanced Protection Features – Built-in safety mechanisms protect against overheating, short circuits, and other potential issues, ensuring smooth, worry-free operation.
Built to Last – Crafted with premium components, this amplifier is designed for durability and consistent performance, even in demanding setups.
Engineered for Exceptional Sound – Carefully designed for optimal audio quality, power efficiency, and reliability, this amplifier brings high-level sound engineering into your system, enhancing every listening session.

All MOSFET Power Supply & Output Stage
Heavy Gauge / High Current Custom Power and Speaker Terminals
2-Ohm Stable
RCA Out Throughput
12dB Octave Low-Pass Filter
Electronic Crossover Network
Bass Boost Circuit
Intelligent Power and
Protection LED Indicator
Soft Turn-on/Turn-off
Turn-On Delay
Fault and Protection Monitoring
4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage

MAX MUSIC POWER 1500W

POWER TERMINAL MANAGEMENT
Positive Terminals: 1 x 4 AWG.
Negative Terminals: 1 x 4 AWG.
Remote Turn-ON Signal: 10 AWG.
Speaker Output Terminals: 10 AWG.


- Frequency Response: 10Hz - 30kHz
- High Pass Crossover Continuously variable (50-1.2kHz)
- Low Pass Crossover Continuously variable (40-250Hz)
- Supply Voltage: 10 - 16V
- Input Impedance: 22kOhm
- Signal to Noise Ratio: >90dB
- Bass Boost: 0
- 12dB Variable
- Variable Input Level Control: 0.2V - 6.0V
- Fuses: 30A recommended (1 x 30A ATC)
- Dimensions (L x W x H): 8.22" x 7.09" x 2.13" (209x180x54mm)

Extra Information

Brand:
ORION
