ORION COBALT Series 2000 Watts MAX 1-Channel Class D Amplifier

ORION

Write a Review
SKU:
OR-CBA2000.1D

Description

ORION COBALT Series 2000 Watts MAX 1-Channel Class D Amplifier

Efficient Class D Power - Unlock high-efficiency, precision bass with advanced Class D amplification, delivering crisp and powerful audio output that enhances every detail of your music.
Massive 2000-Watt Output - Immerse yourself in an intense bass experience with a peak power of 2000 watts, delivering deep bass and dynamic soundscapes designed to elevate your audio system
Precision Tuning - The adjustable crossover enables seamless frequency control, allowing you to fine-tune audio output and optimize speaker performance for an enhanced listening experience.
Enhanced Bass Control - Customize your sound with adjustable bass boost, allowing you to amplify low-end frequencies for rich, resonant bass that makes every beat stand out.
Robust Protection - Advanced circuitry defends against overheating and short circuits, enhancing durability for reliable, long-term performance and providing peace of mind during high-power use.
Compact Build - Its space-saving design offers flexible installation without sacrificing performance.
Engineered for Reliability - Thoughtfully designed for lasting performance and power efficiency in any audio setup.

All MOSFET Power Supply & Output Stage
Heavy Gauge / High Current Custom Power and Speaker Terminals
1-Ohm Stable
Remote Gain Controller Included
RCA Out Throughput
12dB Octave Low-Pass Filter
Electronic Crossover Network
Bass Boost Circuit
Intelligent Power and Protection LED Indicator
Soft Turn-on/Turn-off Turn-On Delay
Fault and Protection Monitoring
4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage

MAX MUSIC POWER 2000W

POWER TERMINAL MANAGEMENT
Positive Terminals: 1 x 4 AWG.
Negative Terminals: 1 x 4 AWG.
Remote Turn-ON Signal: 10 AWG.
Speaker Output Terminals: 10 AWG.


- Frequency Response: 10Hz - 250Hz
- Subsonic (15 - 50Hz)
- Low Pass Crossover Continuously variable (40-250Hz)
- Supply Voltage: 10 - 16V
- Input Impedance: 22kOhm
- Signal to Noise Ratio: >90dB
- Phase Shift: 0/180 Degrees
- Bass Boost: 0 - 12dB Variable
- Variable Input Level Control: 0.2V - 6.0V
- Fuses: 60A recommended (2 x 30A ATC)
- Dimensions (L x W x H): 9.92" x 7.09" x 2.13" (252x180x54mm)
