Description
DS18 PROJECT360 6.5” High-Sensitivity Mid-High Loudspeaker With Neodymium Magnet and Bullet - 350W RMS 8-Ohm - Rotating Recone Design For Quick Repair
INNOVATIVE DESIGN, PREMIUM SOUND
The PROJECT360.BN Series
Designed for enthusiasts who demand powerful midrange and crisp highs, these speakers deliver consistent sound quality whether you're building a daily system or pushing the limits in a high-performance setup. Each speaker is built with a bullet design for better heat dissipation and directional sound projection. Neodymium magnets keep these speakers lightweight, providing powerful performance from a compact footprint.
Exclusive DS18 Technology
What sets PROJECT360 apart is its patent-pending Rotating Recone Design, an innovative, serviceable system that allows for quick and easy maintenance and repair. Built with durable materials and engineered for efficiency, you can spend more time enjoying your system and less time working on it.
- SPECIFICATIONS
- Nominal Diameter: 6.5" / 152mm
- Nominal Impedance: 8 Ohms
- RMS Power Handling: 350 W
- MAX Power Handling: 700 W
- Sensitivity (1w/1m): 100 dB
- Frequency Response: 100Hz–17kHz
- Recommended High–Pass Crossover: 140 Hz
- Sold as: Single unit
- Grill Included: No
- Demodulating Rings: Yes
- Improved Heat Dissipation: Yes
- Cone Shape: Curvilinear
- Speaker Terminals: Spade
- Easy Recone Design: Yes
- MOTOR
- Voice Coil Diameter: 1.75" / 44.5mm
- Voice Coil Former Material: Kapton
- Winding Material: CCAW
- Cone Material: Paper
- Bullet Material: CNC Aluminum
- Bullet Color: Black
- Surround Material: Cloth
- Spider Diameter: 4" / 102mm
- Leads Connection Type: Round Crossed
- Basket Material: Aluminum
- Basket Color/Finish: Black
- Magnet Material: Neodymium
- Magnet Weight: 12.8 oz
- THIELE & SMALL PARAMETERS
- Equivalent Volume: 2.769L / 0.097ft3
- Excursion (one way): 0.85 mm
- Free Air Resonance: 169 Hz
- Mechanical Factor: 5.789
- Electrical Factor: 0.281
- Total Factor: 0.268
- Moving Mass: 14.120 g
- Mechanical Compliance: 0.063 mm/N
- BL Factor: 16.741
- Voice Coil Inductance: 0.060 mH
- Cone Area: 176.71 cm2
- DC Resistance: 5.2 Ohms
- MEASUREMENT
- Overall Diameter: 6.85" / 174mm
- Overall Depth: 3.27" / 83mm
- Front Mount Baffle Cutout: 5.83" / 148mm
- Mounting Depth: 2.72" / 69mm
- Motor Diameter: 3.94" / 100mm
