SPECS

SKU
IXS10.2D
Nominal Diameter
10" / 254mm
Nominal Impedance
2+2 ohms
RMS Power Handling
600w
Maximum Power Handling
1200w
Sensitivity (1w/1m)
84 dB
Frequency Response
20 - 800 Hz
Recommended Lo Pass Crossover
90 Hz

MOTOR

Voice Coil Diameter
2.5" / 63.5mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Paper
Dust Cap Material
Fiberglass
Surround Material
Stitched rubber
Basket Material
Aluminum
Basket Color/Finish
Corrugated Black
Magnet Material
Ferrite
Magnet Weight
62 Oz
Displacement Volume
0.9L / 0.032ft3

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
13.95L / 0.49ft3
Excursion (one way) Xmax
11 mm
Free Air Resonance Fs
38 Hz
Mechanical Factor Qms
5.88
Electrical Factor Qes
0.87
Total Factor Qts
0.76
Moving Mass Mms
200 g
Compliance Cms
88.46 mm/N
Bl Factor BI
13.97
Voice Coil Inductance Le
4.58 mH
Diaphragm Area Sd
333.29 cm2
DC Resistance Re
1.8+1.8 ohms
Efficiency Bandwidth Product EBP
43.6

RECOMMENDED ENCLOSURES

Sealed Internal Volume (minimum)
14.2L / 0.5ft3
Sealed Box Output Response F3
44Hz

MEASUREMENT

Overall Diameter
10.63" / 270 mm
Overall Depth
4.48" / 114 mm
Front Mount Baffle Cutout
9.25" / 235 mm
Mounting Depth
3.66" / 93 mm
Motor Diameter
6" / 154 mm
Gross Single Unit Weight (lb)
15
Single Unit Box Dimensions W x L x H (Inches)
11.25 x 11.25 x 5.75
Quantity of Units in Master Carton
2
Gross Master Carton Weight (lb)
31
Master Carton Dimensions W x L x H (Inches)
12 x 12 x 12.5
