DS18 PRO IP66 RATED 8" 2 OHM MIDRANGE SPEAKER

DS18

Write a Review
SKU:
DS-PRO-SM8.2

Description

DS18 PRO-SM8.2 8" Shallow Water Resistant Mid-Range Loudspeaker 500 Watts 2-Ohm

Key Features

  • 8" Shallow Midrange Speaker 500W MAX / 250W RMS
  • 2-Ohm Impedance for Easy Amplifier Matching
  • Water-Resistant Cone, Dust Cap, and Cloth Surround
  • High Sensitivity (97dB) for Clear, Loud Output
  • 1.5" Kapton Voice Coil with 25oz Ferrite Magnet
  • 2.5" Mounting Depth for Versatile Install Options

SPECS

SKU
PRO-SM8.2
Nominal Diameter
8" / 203.2mm
Nominal Impedance
2 OHMS
RMS Power Handing
250 Watts
Maximum Power Handing
500 Watts
Sensitivity (1w/1m)
97 dB
Frequency Response
65Hz-12KHz
Recommended Hi Pass Crossover
160 Hz



SPECS

Voice Coil Diameter
1.5" / 38.1 mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
25 Oz



THIELE & SMALL PARAMETERS

Vas
25.91L / 0.915ft3
Xmax
8 mm
Fs
100 Hz
Qms
8.051
Qes
1.013
Qts
0.9
Re
2 OHMS



MEASUREMENTS

Overall Diameter
8.23" / 209mm
Front Mount Baffle Cutout
7" / 180 mm
Mounting Depth
2.5" / 63 mm
Overall Depth
2.7" / 69 mm
Product Weight
5 lbs
Product Dimensions
9.0 x 9.0 x 3
M/C Weight
39 lbs
M/C Dimensions
18.5 x 18.5 x 7
M/C QTY
8
Sold In
Piece

Product Overview

DS18 PRO-SM8.2

8” Sealed-Back Slim Mid-Range Loudspeaker 2Ω

DS18’s PRO-SM8.2 is a sealed-back 8” mid-range engineered specifically for motorcycles and tight-fit installs where consistent pressure and output are necessary.

Engineered for Extreme Output
Rated at 250W RMS and 500W MAX at a tight 2-ohm load, the PRO-SM8.2 extracts every ounce of power from your amplifier. Its ultra-efficient 97dB sensitivity ensures you can hear your music LOUD and clear at highway speeds.

Built for Motorcycles and Harsh Environments
The PRO-SM8.2 features a reinforced water-resistant paper cone and a redesigned steel basket engineered to resist vibration at high volume. This latest version of the PRO-SM8.2 features an updated gasket design around the rim. With only a 2.5” mounting depth, it fits effortlessly in tight motorcycle applications where traditional drivers don’t stand a chance.

Precision-Focused Performance
Covering a 65Hz–12kHz frequency range with an 8mm Xmax, the PRO-SM8.2 projects smooth, powerful mid-range tones that cut through all noise. The sealed-back structure means you get controlled mid-range: even in small pods where open-back speakers usually fall short.

If you want mid-range that stays strong no matter how fast you go, the PRO-SM8.2 is the upgrade your motorcycle deserves.
