NVY Full Range Monoblock Amplifier 1800 Watts RMS @ 1-Ohm

• Power
• Total Watts (Peak): 1800W
• RMS Power @ 4 Ohms: 900W
• RMS Power @ 2 Ohms: 1400W
• RMS Power @ 1 Ohm: 1800W

• Audio
• Frequency Response: 15Hz – 20kHz
• Signal-to-Noise Ratio: 85dB
• Efficiency @ 4 Ohms: 89%
• Damping Factor: 82
• Input Impedance: 7.5k Ohms
• Total Harmonic Distortion (THD): 1.0%
• Low-Level Input Range: 0.2V – 6V
• High-Level Input: Yes, with Auto Turn-On
• Selectable Crossover: Band-Pass
• Crossover Filter Range: High Pass: 15Hz – 1kHz - Low Pass: 40Hz – 20kHz
• Bass Boost Range: 0 – 12dB
• Bass Boost Frequency: 45Hz

• Features
• Amplifier Class: Digital
• Amplifier Type: Full-Range Monoblock
• Number of Channels: 1 Channel
• Minimum Impedance: 1 Ohm
• LED Indicators: Power, Protection, Clipping
• Power Input Terminal Size: 4 AWG
• Fuse Size: 220A (External)
• Remote Level Control: Yes
• Cooling Fan: Yes
• Protection Circuits:
• Thermal Protection
• Overload Protection
• DC Output Protection
• Short Circuit Protection
• Voltage Input Protection
• Clipping Protection
• High-Level Speaker Connector: Yes
• Tiffany RCA Terminals: Yes
• LED Clip Indicator: Yes
• High-Efficiency Micro Digital Design: Yes
• Body Color / Finish: Black / Aluminum

Durability You Can Trust

With a stable and reliable digital circuit design, this amplifier features bonded components for extra vibration protection. Its protective coating prevents moisture corrosion on the PCB, enhancing long-term durability. Fully variable crossover filters give you the flexibility you deserve.



Maximized Performance

The NVY-i1800.1D features a Class D design for high efficiency, minimizing power loss and heat. Its compact size allows for compatibility with a wide range of installations, and it includes high-level input with auto turn-on for easy integration into factory systems.

Built-In Protection

This amplifier features power, protection, and clipping LED indicators, keeping you informed about your system’s status. With short-circuit, thermal, DC offset, and high/low voltage protection, it stands as one of the most reliable units in its class. An integrated cooling fan keeps performance consistent under demand.
