SWRGM-49R | Radio Replacement Interface with Steering Wheel Control Retention for GM IOR Vehicles 2019 - Up
The CRUX SWRGM-49R is a Radio Replacement interface for select General Motors vehicles 2019 - Up that are equipped with a 56 pin connector for the headunit. It facilitates the integration of an after-market radio to retain factory features in GM IOR bus vehicles. This enhanced interface is also pre-programmed for retention of steering wheel controls.
– Retains chime functions.
– Pre-programmed to retain factory Steering Wheel Controls
– RAP (Retained Accessory Power).
– Provides illumination, parking brake, reverse, and speed sense outputs.
– Made for non-amplified vehicles or vehicles that will have their amps bypassed.
– Retains factory back-up camera. (Excluding Camaro (IOR) 2019-Up)
Note:- Does not retain Bose amplifier.
– Does not retain OnStar
CHEVROLET
2019-2023 Camaro*
2019-2021 Cheyenne*
2019-2022 Colorado
2019 Cruze
2019-2023 Equinox*
2019-2022 Malibu*
2019-2021 Silverado 1500*
2019-2021 Silverado 2500 HD*
2019-2021 Silverado 3500 HD*
2019-2020 Sonic
2018-2022 Spark
2017-2022 Trax
GMC
2020-2022 Acadia
2019-2022 Canyon
2019- 2021 Sierra 1500*
2019- 2021 Sierra 2500 HD*
2019- 2022 Sierra 3500 HD*
2019-2022 Terrain*
Note:
– Does not retain Bose amplifier.
– Does not retain OnStar
*USE GM49R-EXT, 5 foot Extension Harness is used with GM IOR in cases where the Radio Control Module is located at front passenger side (by the door hinge). Sold separately
Compatible with the following radio code: IOR
NOTE: The radio code can be found in the Glove Box.
NOTE: Newer model GM vehicles are now using a QR code label. If the Service Parts Identification Label is not located in
the Glove Box, reference the Vehicle Certification Label on the driver’s door jam opening for the QR code
