SPECS

SKU
GEN-XX12.4DHE
Nominal Diameter
12"
Nominal Impedance
4+4 Ohm
RMS Power Handling
600W
Maximum Power Handling
1200W
Sensitivity (1w/1m)
86.7 dB
Frequency Response
20Hz - 1.5Khz
Recommended Lo Pass Crossover
80Hz

MOTOR

Voice Coil Diameter
2" / 50.8 mm
Voice Coil Former Material
Black Aluminum
Winding Material
SV
Cone Material
Paper
Dust Cap Material
PPI
Surround Material
Foam
Basket Material
Steel Bakset
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
136 oz
Displacement Volume
1.69L

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
56.436 L
Free Air Resonance Fs
30.5 Hz
Mechanical Factor Qms
3.991
Electrical Factor Qes
0.532
Total Factor Qts
0.469
Moving Mass Mms
154.38g
Compliance Cms
0.175mm/N
Bl Factor BI
19.173N/A
Voice Coil Inductance Le
0.6741mH
Diaphragm Area Sd
475.29cm2
DC Resistance Re
3.2+3.2 ohms
Efficiency Bandwidth Product EBP
57.3

MEASUREMENTS

Overall Diameter
12.44" / 316mm
Overall Depth
7.6" / 193mm
Front Mount Baffle Cutout
10.9" / 277mm
Mounting Depth
6.5" / 165mm
Motor Diameter
6.14"/ 156 mm
Gross Single Unit Weight (lb)
19.5
Dimensions W x L x H (Inches)
13.5 x 13.5 x 9
Quantity of Units in Master Carton
2
Gross Master Carton Weight (lb)
41.5
M/C Dimensions W x L x H (Inches)
14.25 x 14.25 x 19
